characteristic
1. It adopts imported Yaskawa frequency converter and customized PLC program controller, which can add all required functions according to user's setting.
2. The touch screen and button are used to control the acceleration, parking and automatic of the machine, which can be controlled freely at a glance.
3. The machine PLC accurately controls the pneumatic valve to ensure that the temperature accuracy is within 1 ℃.
4. The machine has the functions of automatic temperature control, automatic track counting, automatic turning, automatic parking and manipulation.
5. The machine adopts pneumatic control to open and close the door, and a sealing strip is installed beside the door.
6. The dyeing process can be set according to the user's requirements, and can be centrally controlled by multiple jigging machines at the same time to ensure the dyeing quality.
7. Users can add automatic feeding system, cloth discharging device, etc. according to requirements.
8. According to the user's requirements, we can build machines with all stainless steel housings such as frames to increase the service life of the machine
特點：
1、采用進口安川變頻器，定制PLC程序控制器，可根據用戶要設定增加所需的所有功能。
2、采用觸摸屏及按鈕雙路控制機器加速、停車、自動等控制自如，一目了然。
3、機器PLC精確控制氣動閥門，保證溫度控制精度在1℃之內。
4、機器自動控溫，自動計道、自動調頭、自動停車及擺布功能。
5、機器采用氣動控制開、關門，且在門邊加裝密封條。
6、可根據用戶要求設置染色工序，并同時可以多臺卷染機集中控制，以保證染色質量。
7、用戶可根據要求增加自動加料系統、出布裝置等。
8、可根據用戶要求制作機架等外殼全部用不銹鋼的機器。增加機器使用壽命，一步到位。
主要技術參數Main technical parameter：
織物最大卷布直徑 Max.diameter of cloth roll φ680-1600mm
織物門幅 Max. working fabric width 1600-3600mm
卷布輥直徑 Diameter of main roller φ220-φ400mm
織物線速度 Adjustable fabric rate 10-150m/min
織物張力 Tension of fabrics 3-60kg
裝機容量 Installed capacity 3-18kw
重量 Weight 2-5t
|
